LHB Type Explosion-proof Hoist Double Girder Crane
Authentication mark:
This crane is mainly used in chemical plants, oil refineries, paint workshops, gas production facilities, pharmaceutical manufacturing, and other hazardous environments with explosive gases or combustible dust.
Capacity:
1 t – 32 t (customizable)
Lifting Height:
6 m – 20 m (customizable based on building clearance)
Span:
7.5 m – 25.5 m customizable
Voltage/Hertz:
3 Phase 380V 50hz
Working Class:
A4, A5, A6 (Medium to heavy duty)
Explosion-proof Level::
Ex d IIB T4 / Ex d IIC T4 / Ex tD A21 IP65 T135°C
Get A Free Quote
Introduction
Application Scenario
Advantages
Structural Diagram And Parameter Table
INTRODUCTION
What is this?
The LHB type explosion-proof hoist double girder crane is a compact heavy-duty overhead crane designed for safe operation in hazardous environments. It features a double main beam structure with an explosion-proof electric hoist running between or on top of the girders. Unlike traditional wire rope trolley cranes with open motors, all electrical components including hoist motors, controllers, limit switches, and control pendants are enclosed in certified explosion-proof enclosures. If your facility requires medium to heavy lifting capacity up to 32 tons in classified hazardous zones with limited headroom, this product is designed for you.
Why choose an explosion-proof hoist double girder crane over a traditional explosion-proof wire rope trolley crane?
Compared to traditional explosion-proof wire rope trolley cranes, the LHB hoist solution offers four core advantages:
First, more compact design – the integrated explosion-proof hoist occupies less headroom space, providing higher effective lifting height under the same building clearance.
Second, lower self-weight – the hoist-type design reduces overall crane weight by 15%-25% compared to wire rope trolley cranes, lowering building load requirements.
Third, easier maintenance – modular explosion-proof hoist components allow quick replacement and reduce downtime during maintenance.
Fourth, lower investment cost – simplified structure with hoist integration reduces manufacturing cost by 20%-30% while maintaining the same explosion-proof certification.
Get compact explosion-proof lifting with higher efficiency and lower cost.
What can we do for you?
We understand that every customer has different hazardous zone classifications, different building structures, and different capacity requirements. Therefore, we offer flexible customization options: explosion-proof levels from Ex d IIB T4 to Ex d IIC T4; temperature classes T1 to T6; capacity from 1 ton to 32 tons; span from 7.5 meters to 25.5 meters; control options of explosion-proof pendant, explosion-proof remote radio, or cabin with purge system; VVVF speed control for smooth start/stop. Whether your hazardous area contains gasoline vapors, hydrogen gas, or combustible dust, we can match the appropriate explosion-proof rating for your specific zone.
Unsure? Don't know?
Not sure what explosion-proof level your facility requires? Not sure whether a hoist-type or trolley-type crane suits your headroom? No problem. Just tell us: your hazardous zone classification (Zone 1, Zone 2, Zone 21, Zone 22), your building clearance height, and your required lifting capacity. Our engineers will provide you with an accurate quote and CAD drawings within 24 hours. Click the button below or contact us via WhatsApp/email to get your customized solution.
💡 Tip: We offer free selection consulting. Even if you are unsure about specific explosion-proof requirements, feel free to describe your hazardous environment and building structure, and we will calculate for you.
The LHB type explosion-proof hoist double girder crane is a compact heavy-duty overhead crane designed for safe operation in hazardous environments. It features a double main beam structure with an explosion-proof electric hoist running between or on top of the girders. Unlike traditional wire rope trolley cranes with open motors, all electrical components including hoist motors, controllers, limit switches, and control pendants are enclosed in certified explosion-proof enclosures. If your facility requires medium to heavy lifting capacity up to 32 tons in classified hazardous zones with limited headroom, this product is designed for you.
Why choose an explosion-proof hoist double girder crane over a traditional explosion-proof wire rope trolley crane?
Compared to traditional explosion-proof wire rope trolley cranes, the LHB hoist solution offers four core advantages:
First, more compact design – the integrated explosion-proof hoist occupies less headroom space, providing higher effective lifting height under the same building clearance.
Second, lower self-weight – the hoist-type design reduces overall crane weight by 15%-25% compared to wire rope trolley cranes, lowering building load requirements.
Third, easier maintenance – modular explosion-proof hoist components allow quick replacement and reduce downtime during maintenance.
Fourth, lower investment cost – simplified structure with hoist integration reduces manufacturing cost by 20%-30% while maintaining the same explosion-proof certification.
Get compact explosion-proof lifting with higher efficiency and lower cost.
What can we do for you?
We understand that every customer has different hazardous zone classifications, different building structures, and different capacity requirements. Therefore, we offer flexible customization options: explosion-proof levels from Ex d IIB T4 to Ex d IIC T4; temperature classes T1 to T6; capacity from 1 ton to 32 tons; span from 7.5 meters to 25.5 meters; control options of explosion-proof pendant, explosion-proof remote radio, or cabin with purge system; VVVF speed control for smooth start/stop. Whether your hazardous area contains gasoline vapors, hydrogen gas, or combustible dust, we can match the appropriate explosion-proof rating for your specific zone.
Unsure? Don't know?
Not sure what explosion-proof level your facility requires? Not sure whether a hoist-type or trolley-type crane suits your headroom? No problem. Just tell us: your hazardous zone classification (Zone 1, Zone 2, Zone 21, Zone 22), your building clearance height, and your required lifting capacity. Our engineers will provide you with an accurate quote and CAD drawings within 24 hours. Click the button below or contact us via WhatsApp/email to get your customized solution.
💡 Tip: We offer free selection consulting. Even if you are unsure about specific explosion-proof requirements, feel free to describe your hazardous environment and building structure, and we will calculate for you.
APPLICATION SCENARIO
[1] Chemical Plants – Lifting chemical drums, reactors, mixing vessels, and heavy equipment in areas with flammable gas hazards such as ethylene, propylene, or methanol vapors.
[2] Oil Refineries – Handling pumps, valves, heat exchangers, and heavy maintenance equipment in refining units with hydrocarbon gas hazards.
[3] Paint and Coating Workshops – Lifting paint drums, mixing tanks, spraying equipment, and finished products in solvent vapor environments. Compact design suits low-clearance paint booths.
[4] Pharmaceutical Manufacturing – Handling active pharmaceutical ingredients (APIs), solvent drums, reactors, and equipment in facilities with explosive alcohol or solvent vapors.
[5] Gas Production Facilities – Moving cylinders, heavy equipment, and materials in natural gas processing plants, hydrogen production facilities, or acetylene stations.
[6] Coal Chemical Plants – Lifting equipment and materials in coal gasification, methanol production, and other coal chemical processes with combustible gas risks.
[2] Oil Refineries – Handling pumps, valves, heat exchangers, and heavy maintenance equipment in refining units with hydrocarbon gas hazards.
[3] Paint and Coating Workshops – Lifting paint drums, mixing tanks, spraying equipment, and finished products in solvent vapor environments. Compact design suits low-clearance paint booths.
[4] Pharmaceutical Manufacturing – Handling active pharmaceutical ingredients (APIs), solvent drums, reactors, and equipment in facilities with explosive alcohol or solvent vapors.
[5] Gas Production Facilities – Moving cylinders, heavy equipment, and materials in natural gas processing plants, hydrogen production facilities, or acetylene stations.
[6] Coal Chemical Plants – Lifting equipment and materials in coal gasification, methanol production, and other coal chemical processes with combustible gas risks.
ADVANTAGES
[1] Certified Explosion-proof – ATEX, IECEx, or GB certified for safe operation in hazardous zones.
[2] Compact Double Girder Design – Provides high load capacity (up to 32t) with less headroom than trolley-type cranes.
[3] Lighter Self-weight – 15%-25% lighter than wire rope trolley explosion-proof cranes, reducing building load.
[4] Easier Maintenance – Modular explosion-proof hoist allows quick component replacement.
[5] Smooth Operation – VVVF speed control available for precise positioning of hazardous materials.
[6] Lower Cost – 20%-30% less expensive than traditional explosion-proof trolley cranes.
[2] Compact Double Girder Design – Provides high load capacity (up to 32t) with less headroom than trolley-type cranes.
[3] Lighter Self-weight – 15%-25% lighter than wire rope trolley explosion-proof cranes, reducing building load.
[4] Easier Maintenance – Modular explosion-proof hoist allows quick component replacement.
[5] Smooth Operation – VVVF speed control available for precise positioning of hazardous materials.
[6] Lower Cost – 20%-30% less expensive than traditional explosion-proof trolley cranes.
STRUCTURAL DIAGRAM AND PARAMETER TABLE
| Parameter | Specification |
|---|---|
| Working Class | A4, A5, A6 |
| Capacity | 1 t – 32 t |
| Span | 7.5 m – 25.5 m |
| Lifting Height | 6 m – 20 m |
| Lifting Speed | 4 – 10 m/min |
| Trolley Travelling Speed | 20 – 35 m/min |
| Crane Travelling Speed | 20 – 45 m/min |
| Temperature Class | T1 – T6 (customizable) |
| Power Supply | 380V / 50Hz / 3-phase |
| Temperature (Ambient) | -20°C to +50°C |
| Hoist Type | Explosion-proof electric wire rope hoist |
| Girder Type | Double girder – box-section with explosion-proof hoist mounting |
