Manual operation type chain hoist
Authentication mark:
This hoist is mainly used in construction, factory maintenance, and mining field operations.
Capacity:
0.5 ton – 20 tons (Common: 0.5t, 1t, 2t, 3t, 5t, 10t, 20t)
Lifting Height:
2.5 m – 3 m (Customizable up to 30 m)
Get A Free Quote
WhatsApp
Introduction
Application Scenario
Advantages
Structural Diagram And Parameter Table
INTRODUCTION
A Manual Chain Hoist (commonly known as a hand chain block or lever block) is a portable, human-powered lifting device. It uses internal spur gears and a load chain mechanism to convert hand-pull force (via a hand chain loop or ratchet lever) into mechanical advantage, allowing an operator to lift, lower, or tension heavy loads without electricity.
APPLICATION SCENARIO
[1] Construction sites – Lifting materials, tools, and equipment in remote areas without electricity.
[2] Warehouse maintenance – Hoisting heavy spare parts or machinery during installation.
[3] Shipyards and docks – Tightening and positioning heavy components on vessels.
[4] Factory maintenance pits – Raising pumps, motors, or gearboxes for repair.
[5] Mining and field operations – Lifting equipment in explosive environments (non‑sparking version available)
[2] Warehouse maintenance – Hoisting heavy spare parts or machinery during installation.
[3] Shipyards and docks – Tightening and positioning heavy components on vessels.
[4] Factory maintenance pits – Raising pumps, motors, or gearboxes for repair.
[5] Mining and field operations – Lifting equipment in explosive environments (non‑sparking version available)
ADVANTAGES
[1] No power required – Operates anywhere, ideal for remote or outdoor sites.
[2] Low cost – Affordable purchase and zero energy consumption.
[3] Simple and durable – Mechanical design with minimal maintenance.
[4] Precise load control – Hand chain allows fine positioning.
[5] Portable and lightweight – Easy to carry and rig in different locations.
[2] Low cost – Affordable purchase and zero energy consumption.
[3] Simple and durable – Mechanical design with minimal maintenance.
[4] Precise load control – Hand chain allows fine positioning.
[5] Portable and lightweight – Easy to carry and rig in different locations.
STRUCTURAL DIAGRAM AND PARAMETER TABLE
| Parameter | Specification |
|---|---|
| Rated Capacity | 0.5 ton – 20 tons (Common: 0.5t, 1t, 2t, 3t, 5t, 10t, 20t) |
| Standard Lifting Height | 2.5 m – 3 m (Customizable up to 30 m) |
| Test Load | 150% of rated capacity |
| Safety Factor | ≥4 times rated capacity |
| Load Chain Falls | 1 – 8 (Increases with capacity) |
| Load Chain Diameter | 6mm – 10mm (Grade 80 high-strength manganese steel chain) |
| Full Load Hand Pull Force | 160N – 430N (Approx. 16kg – 43kg) |
| Net Weight | 8kg – 140kg (Varies with capacity and lift height) |
| Hook Material | Alloy steel, forged type with safety latch |
| Housing Material | High-quality alloy steel, fully enclosed stamped structure |
| Brake System | Double pawl brake system |
| Applicable Standards | JB/T 7334—2016 / CE / ASME B30.16 |
